PRO SERIES
ULTRASONIC CLEANING BATH RBS MSW-269
This is a small description
- Selection support
- Configuration guidance for your application
- Delivery
- Pan-India coordination from Mohali
- After-sales
- Installation, calibration and maintenance support
Product details
Features and construction
Description
- Constant temperature heating one-click degassing: Hidden heating tube, constant temperature heating, the temperature can be adjusted from room temperature ~100°C
- Eliminate air bubbles in the cleaning medium to improve cleaning efficiency: Degassing function: Ultrasonic waves use the degassing function to discharge oxygen and air bubbles in the cleaning medium during operation. Improve cleaning efficiency while preventing product oxidation.
- All stainless steel sink one-time stamping forming: SUS304 stainless steel inner tank, no welding joints, good waterproof performance. Corrosion-resistant one-time stamping forming, side grooves are integrally bent, strong load-bearing, more beautiful.
- Wide range of applications: Widely used in machinery/ electronics/ medicine/ optics/ teaching and other industries.
- The body is integrated, simple in shape and easy to clean.
- Operating frequency: 40Khz
- Timing Range: 0 ~ 60 min
- Settable Temperature: Room Temperature - 100°C
- Heating: Yes
- Degassing Function: Yes
Technical data
Specifications and models
| Model | #RBS UCB-20 (PRO) | #RBS UCB-30 (PRO) | #RBS UCB-60 (PRO) | #RBS UCB-100 (PRO) | #RBS UCB-150 (PRO) | #RBS UCB-200 (PRO) | #RBS UCB-300 (PRO) |
|---|---|---|---|---|---|---|---|
| Capacity | 2.0 Ltrs | 3.0 Ltrs | 6.0 Ltrs | 10.0 Ltrs | 15.0 Ltrs | 20.0 Ltrs | 30.0 Ltrs |
| Inner Tank Size | 150x138x100 | 238x138x100 | 302x152x150 | 161x149x217 | 325x295x150 | 498x296x150 | 502x298x200 |
| Overall Dimensions (mm) | 302x239x150 | 251x149x217 | 311x161x272 | 308x248x315 | 335x305x315 | 510x308x343 | 510x308x343 |
| Number of Vibration Heads | 1 | 2 | 3 | 4 | 6 | 6 | 8 |
| Ultrasonic Power | 60W | 120W | 180W | 240W | 360W | 360W | 480W |
| Drain Valve | NO | NO | NO | YES | YES | YES | YES |
| Handles | NO | YES | NO | YES | YES | YES | YES |
